| Feature |
Specification |
| 8-Port Valve |
Electrically Actuated 8-Port, 45° Rotation, Replaceable
Valve Rotor (Optional Teflon or PEEK) Ambient to 250
degrees C |
| Dimensions |
12 “W x 21” D x 16” H |
| *Operating System |
On-Board Windows XPe Operating System |
| Programmability |
Built-in EPC allows programmable flows in all steps
of the analysis |
| *Display |
10” Color VGA Touchscreen Monitor |
| *Diagnostic |
Diagnostic touch screen allows local control and
automated troubleshooting |
| Transfer Line |
SilcoSteel Tubing, 0.020 ID 60" Standard
Siltek Tubing & Siltek Treated Fittings throughout the
Sample Pathway
Ambient to 250 degrees C |
| *Traps |
Traps are mounted in front for easy access.
Industry standard straight 12” traps.
Ambient to 350 degrees C cools from 250 degrees C
to 40 degrees C in 70seconds or less at ambient lab
temperatures(20-22 degrees C) |
Glassware
External Transfer Line
Sample Mount
Sample Heater (optional) |
5-ml Fritted Sparge Vessel Standard (25-ml Optional)
Ambient to 250 degrees C.
Ambient to 90 degrees C
Ambient to 115 degrees C |
| Power Requirements |
Standard Unit 100-130VAC (+/-10%)/50/60Hz (800 VA max)
Optional Unit 230VAC (+/-10%)/50/60 Hz |
| Gas Supply |
Ultra High Purity (99.999%) Pure Helium or Nitrogen |
| Incoming Gas Pressure |
60-80 PSI |
